Performance:

technical parameter:

1. Leads: 12 leads synchronous acquisition, 6 leads synchronous printing;

2. Input mode: anti-defibrillation protection input;

3. Language: with simplified Chinese and English, support Pinyin input method and Wubi input method;

4. DC working time: large capacity battery can continuously print 1080 ECG reports;

5. File storage format: xml, bmp, pdf, jpg multiple file formats;

6. Interface: USB, SLAVE interface, can be connected to ECG workstation software;

7. Display screen: 800 × 480 pixels 7-inch LED backlit TFT LCD, the screen can display 1mm grid lines;

8. Input device: T9 keyboard input;

9. Printing: USB MASTER interface, which can be connected to a printer, and print ECG with ordinary A4 paper;

10. Input loop current: ≤0.05uA;

11. Input impedance: ≥50MΩ;

12. Calibration voltage: 1mV ± 5%;

13. Standard sensitivity: 10mm / mV ± 5%;

14. Sensitivity: 2.5, 5, 10, 20mm / mV;

15. Polarization resistance voltage: ≥ ± 300mV;

16. Common mode rejection ratio:> 89dB,> 100dB (open the filter);

17. Frequency response: 0.05 ～ 150Hz;

18. Noise level: ≤15uVp-p;

19. Time constant: ≥3.2s;

20. Acquisition rate: normal 1000sps / channel, pacing 10000sps / channel;

21. A / D conversion: 12 bits;

22. Temperature drift: ≤0.5mm / ℃ in the temperature range of 5-40 ℃;

23.xml, bmp, pdf, jpg multiple file formats to save;

24. Filtering: EMG filter 25Hz / 30Hz / 40Hz; AC filter: 50Hz / 60Hz; baseline filter: 0.05Hz / 0.15Hz / 0.25Hz // 0.32Hz / 0.5Hz / 0.67Hz / ADS

25 .; Low-pass filter: 75Hz / 100Hz / 150Hz;

26. Accurate ECG automatic diagnosis function, providing heart rate, PR interval, QRS complex time limit, QT interval, Q-Tc, P axis, QRS axis, T axis, R (V5) amplitude, S (V1 ) Amplitude, R (V5) + S (V1) amplitude and other measurement parameters and automatic diagnosis conclusion;

27. Recording method: with automatic recording, manual recording and rhythm recording;

28. Retrospective record: the ECG waveform measured in the first 10 seconds can be recorded;

29. Paper speed: 5, 6.25, 10, 12.5, 25, 50 mm / s ± 5%;

30. Recording mode: automatic 3ch × 4, 3ch × 4 + 1, 3ch × 4 + 3, 6ch × 2, 6ch × 2 + 1;

31. Storage: Built-in 4G SD card can store more than 10,000 sets of ECG data;

32. Interface type: USB master interface × 1, USB slave interface × 1, SD card interface × 1, LAN port × 1, equipotential terminal interface × 1, patient lead wire interface × 1;

33. Power requirements: AC: 100-240V 50Hz, DC: built-in rechargeable lithium battery and charger;

34. DC working time: large capacity battery can continuously print 1080 ECG reports;

35. Recording paper: 110mm roll paper;

36. Storage: Built-in 4G SD card can store more than 10,000 sets of ECG data;

37. System upgrade: software upgrade through SD card;

38. Sleep mode: The screen supports sleep power saving function;

Can be interconnected with the information terminal equipment, the test results can be passed in at any time.
